Big Pen Nursery Design

• Click here to see the design

• Each pig to 20 kg requires 0.2 m2 (2.2 sq feet) per pig.

• One turkey drinker to 50 weaners seems adequate

• Feeders as required. Lean machines are working well in this type of building.

• Temperature in sleeping area follows typical weaner cooling curve from 30 degrees Celsius at 6 kg to 22 at 20 degrees Celsius with minimal variation per 24 hours (less than 1 degrees Celsius).

• The feeding and dunging areas should be cooler at 24 degrees Celsius.

• Solid insulated sleeping area. Slatted plastic floor for exercise, dunging area.

• The three zones concept is an important component to this plan's success

• The concept is to have 3 zones, sleeping, eating and dunging.

• Depending on the ventilation, you could end up with the sleeping area in the middle with eating on either side and dunging on either side, therefore 5 zones.
